Common Specifications for Measuring Equipment:

- Measuring Medium: Solid / Liquid / Powder / —

- Measuring Range: 0.3m to 150m

- Process Connection: Flange / Thread

- Process Temperature: -40°C to 250°C

- Process Pressure: -0.1 to 0.3/4MPa

- Antenna Size: 32mm to 78mm (lens antenna)

- Antenna Material: PTFE / Stainless Steel / Other

- Accuracy: ±1mm

- Protection Level: IP67

- Frequency: 123GHz

- Launch Angle: 3°

- Power Supply Options:

    - Two-wire: DC 24V

    - Four-wire:

        - DC 12-24V

        - AC 220V

- Outer Covering: Aluminum / Plastic / Stainless Steel

- Signal Output Options:

    - Two-wire: 4-20mA / Hart Protocol

    - Four-wire: 4-20mA / Modbus-RS485

Certainly, here is the text without bold formatting:

- Characteristic: Millimeter-wave radar, with a measurement accuracy of up to ± 2mm and a minimum blind area of 0.05m.

- Smaller antenna size to meet the measurement of more working conditions.

- A variety of lens antennas, smaller emission angles, more concentrated energy, and stronger echo signals, so it has higher reliability than other radar products under the same industrial and mining conditions.

- It has stronger penetrability and can be used normally under the condition of adhesion and condensation.

- ATVUK-FMR series products have a larger dynamic signal range and more stable measurement for low dielectric constant media.

- Multiple measurement modes, the radar response time is less than 1S in the fast measurement mode.

Range:

Measurable product:

- Solid measurement

  - Powder

  - Granule

  - Block

  - Low dielectric constant plastic particles

- Liquid measurement

  - Reactor level

  - Large steam level

  - Foam product level

  - Crystal product level

  - Ultra high temperature product level

  - Ultra high-pressure product level

  - Hygienic product level
