Frequency Sweep Microwave Level Switch
BROTEK MAKE Admittance Microwave Level
Switch with Frequency Sweep Technology from SI India is a versatile and
universal level switch that is not affected by foam, condensate, or residue. It
is designed using microwave measuring principles and can detect both conductive
and non-conductive mediums, making it suitable for a wide range of
applications, including liquids, solids, and solid powders.
Product Feature
Key Specifications:
- Material: The enclosure and
connection are made of S.S. 316L, while the measuring point is made of PEEK.
- Switch Delay: Adjustable from 0
to 3 seconds.
- Output: Offers various output
options, including NO, NC, NPN, and PNP.
- Power Supply: Supports a power
supply range of 12 to 33V DC, with 24V DC being the ideal voltage.
- Power Consumption: Consumes less
than 33mA.
- Protection: Rated IP66 for
protection against dust and water.
- Pressure Limit: Can handle
pressures up to 10 bar.
- Temperature Limit: Available in
different temperature versions, with options ranging from -40°C to 100°C.
- Process Connection: Threaded.
- Weight: Approximately 0.3 kg.
Product Features:
- The SI microwave frequency sweep
level switch is designed to be hygienic and has no dead-end measuring point,
making it suitable for applications like Clean-in-Place (CIP), Wash-in-Place
(WIP), and Sterilization-in-Place (SIP).
- It is available with different
process connection options to meet the specific requirements of different
industries.
- The level switch is
explosion-proof with EXD IIC T6 Gb certification and is also certified for
safety with a Class SIL-3 rating.
- It holds CE certificates for
both electromagnetic compatibility (EMC) and low voltage (LVD).
- The switch provides a
single-point solution for various level switch types, including vibrating fork,
capacitance, and float level switches. It is compatible with both conductive
and non-conductive liquids, solids, and powders.
Product Appication
Applications:
- The SI microwave level switch is
suitable for applications where you need high and low-level alarms, as well as
pump dry-run alarms.
In summary, the SI Admittance
Microwave Level Switch with Frequency Sweep Technology is a versatile and reliable
instrument suitable for a wide range of level measurement applications. Its
robust design, certifications, and compatibility with different media make it a
valuable solution for various industries. For more detailed information, it is
recommended to check the product video or contact the company directly.
