OVAL GEAR FLOW METER
Product Specification ::
BROIL TECH Digital oval gear positive displacement flow meter is approved by weight and measurement ( W&M) Legal metro-logy government of India for measuring oil and fuel other than water As per ( MID 005)
Oval
gear fuel flow meter is a positive displacement volumetric flow meter,
available with RS 485/Pulse/Current/Hart output and inbuilt flow rate and
totalize digital display,
positive displacement flow measurement has accurate and precision teethed two oval shape gear, Gear rotate when flow pass on measuring chamber and Magnetic pickup sensor/ Hall sensor use for measuring rotation of gear, and each rotation equal to fix value of fluid volume,
Material
of construction:
Rotor and casing : Aluminum anodize/ PPS/S.S-316
O-ring : NBR/VITON/SILICON
Shaft : Stainless Steel/ hastelloy
Product Feature
Digital
Fuel Flow Meter available with :
--- Inline battery operated digital display
---
4 to 20 mA output inline digital display
---
Panel mount digital display
---
Mechanical counter flow meter
Technical specification:
CE certified product
Working principle: oval gear positive displacement
Accuracy
(standard installation position) : ±0.1% FSD or 0.5%RS
Repetability
:0.01 %
Maximum working pressure:
MPa = 50 bar for aluminum body
MPa
= 250 bar for s.s. body
above
250 bar please contact company
Fluid &Ambient temperature: -40 to 150°C
Power voltage: 3 - 24V DC
Product Appication
Oval
gear fuel flow meter Application selection as per bellow detail
:
Aluminum wetted part : kerosene, Gasoline, diesel, light oil, heavy oil
:
S.S. wetted part : wine, bear, alcohole, milk, juice, coffee, tea
:
PPS wetted part : for all chemical and pharma drug
Product
Applications ::
Fuel
Oil
Acid&
Chemical
High
Viscosity Liquid
