Ultrasonic Flow Meter - Battery Operated
Star Senostek Industries - Ultrasonic Flow Meter
Star Senostek Industries collaborates with leading German
and Russian companies to provide sales and services for Ultrasonic Flow Meters.
These Ultrasonic Flow Meters are backed by the reputation of German and Russian
companies known for their quality and have certifications such as OIML, MID,
2014/32/EC, EX, and IP 65.
Advantages of Ultrasonic Flow Meter - Battery Operated:
- OIML/MID 001/2014/32/EC certified.
- Independent of power failure and power-off situations.
- Not affected by water pollution levels, no need for
filters.
- No pressure loss in the pipeline.
- High measurement stability.
- Electronic unit positioned directly on the spool piece.
- LCD on/off button for saving battery charge.
- Easy commissioning.
Product Feature
Applications:
- Residential water consumption metering (both cold and hot
tap water).
- Water consumption metering at industrial enterprises.
- Water metering at pipeline control points.
- Irrigation.
Ultrasonic Flow Meter Specification:
- Nominal Diameter of the Pipeline (DN): 32 ÷ 300
- Accuracy: From ±1.0%
- Flow Velocity Range (m/s): 0.04 ÷ 5
- Fluid Temperature Range (°C): 0 ÷ 90 (130 on request)
- Ambient Temperature for Transmitter (°C): 5 ÷ 65
- Maximum Pipeline Pressure (MPa/bar): 1.6/16 (2.5/25 on
request)
- Protection: IP65 (IP67 or IP68 on request)
- Measurement Data Logging, Number of Records:
- Hourly log: 120
records
- Daily log: 45
records
- Monthly log: 48
records
- Lithium Battery Life (years): 10
Outputs:
- LCD
- Universal Output
- RS-485 Interface (Modbus)
- Wired or Wireless M-Bus Interface (available on request)
Product Features:
- OIML/MID 001/2014/32/EC certified ultrasonic flow meter
that is battery operated with a remarkable 12-year battery life.
Range:
- The Ultrasonic Flow Meter covers a line size range from 32
mm to 300 mm.
Product Appication
Product Applications:
- Pure Water
- Waste Water
- Acid & Chemical
- Heat/SIU (Sensible Heat and Latent Heat in heating,
ventilation, and air conditioning systems)
Star Senostek Industries offers reliable and certified
Ultrasonic Flow Meters that are suitable for various applications and provide
long-lasting performance with the convenience of battery operation. These
meters are capable of accurately measuring flow rates in different environments
and are well-suited for residential, industrial, and irrigation applications.
